Chapter 22 Vascular Anomalies of the Fundus CAROLINE R. BAUMAL, JAY S. DUKER and GARY C. BROWN Table Of Contents |
Choroidal and retinal vascular anomalies may be associated with systemic disorders. Accurate diagnosis is therefore critical. In most instances, careful ophthalmoscopic examination is sufficient, In some cases, ancillary tests such as intravenous fluorescein angiography (IVFA), indocyanine green (ICG) angiography, ultrasonography, computed tomography (CT) and magnetic resonance imaging (MRI) are necessary either to confirm the diagnosis or to rule out associated systemic disorders. |
CHORIOVAGINAL VEIN |
A choriovaginal vein is an uncommonly recognized, unusually large choroidal vessel located within the posterior pole, The choriovaginal vein passes from the choroid through the sclera at the margin of the optic disc to terminate in the venous plexus of the pial sheath of the optic nerve.1 This establishes an indirect communication between the choroidal and retinal venous systems through the pial branches of the central retinal vein.2 It is generally seen temporal to the optic nerve and is predominantly noted in lightly pigmented, myopic fundi1,3 (Fig. 1). This entity was described in a case of trisomy 13 with congenital glaucoma, although it is not typically associated with any systemic abnormalities.4 |
PERSISTENT HYALOID ARTERY | |
The hyaloid vessels develop around the fifth week after conception. The
hyaloid artery provides the bulk of blood supply to the developing posterior
segment and lens during late embryologic and early fetal development. Its
branches include the tunica vasculosa lentis and the vasa
hyaloidea propia. Spontaneous regression of the fetal hyaloid artery commences
at the start of the third trimester (28 weeks),5–7 Ultrasound examination during pregnancy typically demonstrates the hyaloid
artery in fetuses of 20 weeks' gestational age or younger, whereas
its presence on ultrasound in the mid-third trimester is uncommon
in healthy fetuses.8 A persistent hyaloid artery represents incomplete regression and is noted clinically as a single threadlike vessel emanating from the optic disc. It travels in a sinuous course anteriorly through the vitreous cavity within Cloquet's canal. Persistent hyaloid arteries can traverse the entire length of the vitreous cavity to insert on the posterior capsule of the lens (Fig. 2). When all but the anterior lens insertion of the hyaloid artery regresses, the remaining focal posterior lens capsule opacity is called Mittendorfs dot. At birth, up to 95% of premature infants have hyaloid artery remnants. Such remnants also have been noted in 3% of full-term infants.6 Persistent hyaloid arteries may be filled with blood. When they are blood filled, vitreous hemorrhage may occur. This can be spontaneous, precipitated by trauma or by a posterior vitreous detachment.9,10 It has been postulated that rapid eye movements during sleep produce traction, leading to rupture of a freely floating hyaloid artery in young individuals.11 Other ocular conditions that may be associated with a persistent hyaloid artery include strabismus, cataract, amblyopia, and nystagmus.10 A persistent hyaloid artery typically does not need treatment, but recurrent vitreous hemorrhage secondary to this condition may require vitrectomy. Also, a persistent, patent hyaloid artery may complicate attempts at surgical repair in infants with the condition called persistent hyperplastic primary vitreous or with retinal detachment caused by retinopathy of prematurity.12
|
PREPAPILLARY LOOPS | |
Prepapillary vascular loops were first recognized by Leibrich in 1871.13 These congenital vascular anomalies extend into the vitreous cavity. They
appear as corkscrew, spiral, or hairpin vessels overlying the optic
disc and are contiguous with the normal retinal circulation (Fig. 3A). They can arise from the central retinal vessels, a branch retinal
vessel, or a cilioretinal vessel,6,7,14 About one third of prepapillary loops are encased in a fibroglial sheath, and
they are present bilaterally in approximately 10% of affected
persons,6 Eyes containing a prepapillary loop have an unusually high prevalence
of associated cilioretinal arteries. On ophthalmoscopic examination, prepapillary
loops may pulsate. IVFA has shown that 95% of prepapillary
loops are arterial in origin.6,15 Prepapillary loops were once believed to be remnants of the hyaloid artery, It is now thought that they represent developmental anomalies that occur when mesenchymal cells destined to differentiate into mature retinal vessels proliferate within Berg-meister's papilla.16 Histopathologic study has demonstrated communication of a prepapillary loop with the retinal arterial system.16 The prepapillary loop was supported by a connective tissue sheath that was lined by a cellular lamina continuous with the inner retina.
The major complication occurring with prepapillary loops is retinal arterial obstruction within the territory supplied by the loop (see Fig. 3B). This is believed to occur secondary to turbulent flow, endothelial damage, and subsequent thrombus formation.15 Vitreous hemorrhage, amaurosis fugax, hyphema, and retinal venous macrovessel also have been reported.15,17–20 There are no associated systemic abnormalities. Two studies report a familial occurrence of prepapillary loops, although a definite hereditary pattern has not been identified.21,22 |
HEREDITARY RETINAL ARTERY TORTUOSITY | |
Hereditary retinal artery tortuosity is a rare, congenital, autosomal dominantly
inherited condition characterized by extreme tortuosity of the
retinal arteries. Patients with this entity may present acutely with
visual loss from a superficial macular hemorrhage that occurs spontaneously
or after relatively minor trauma.14,23–25 Vision typically returns to normal as the retinal hemorrhage clears. The
artery tortuosity is most marked in the macular region, whereas the
retinal veins remain normal (Fig. 4). The vascular tortuosity progressively increases with age.25 On IVFA, the tortuous retinal arteries are competent, and there is no
microvascular cause for the macular hemorrhage. Histologic study by light
microscopic examination in one case failed to reveal any structural
abnormality in the arteriolar wall.23 No systemic vascular abnormality has been detected in these patients.26 The other syndrome that typically produces isolated retinal arteriolar
tortuosity without venous involvement is coarctation of the aorta.27 It may be reasonable to examine family members for arteriolar tortuosity
before subjecting an affected individual to an extensive medical evaluation. Hereditary
retinal artery tortuosity should be differentiated
from other systemic diseases that can induce retinal vascular tortuosity (affecting
both the arteries and veins) including hypoxic
retinal syndromes (e.g., sickle cell disease, congenital heart disease), leukemia, dysproteinemias, familial
dysautonomia, mucopolysaccharidosis, and Fabry's
disease.14
|
INHERITED RETINAL VENOUS BEADING |
Meredith reported a family in whom some of the members presented with prominent bilateral beading and segmentation of their retinal veins.28 Associated findings included beading of the conjunctival veins, retinal capillary nonperfusion, microaneursym formation, altered vascular permeability with lipid exudation, retinal edema, retinal neovasvularization, and vitreous hemorrhage. The family's pedigree was consistent with autosomal dominant inheritance. These retinal vascular changes may represent an unusual manifestation of renal disease, since two of the five patients concurrently had Al-port's syndrome, A second reported pedigree showed no evidence of renal disease, although affected members did display a relative neutropenia on peripheral blood examination.29 |
RETINAL MACROVESSELS |
A congenital retinal macrovessel is an aberrant, enlarged branch retinal
vessel that supplies or drains the macular area, crossing the horizontal
raphe (Fig. 5A). They usually are veins. The condition typically is unilateral, benign, and
ophthalmoscopically stable. This entity often is detected
on routine examination.14 Visual acuity is typically unaffected, although concomitant foveal cysts
have been noted.30 IVFA may reveal delayed drainage of dye from the macrovessel, associated
microvascular abnormalities, and retinal capillary nonperfusion30 (see Fig. 5B). On occasion, retinal macrovessels may be accompanied
by similar vascular anomalies affecting the conjunctiva and mouth.14
The retinal arteries and the accompanying capillary bed are relatively normal in eyes with congenital retinal macrovessels. This is in contrast to congenital retinal arteriovenous communications, which do not feature a normal intervening capillary bed. |
ARTERIOVENOUS COMMUNICATIONS |
Congenital retinal arteriovenous communications are abnormally dilated
retinal vessels that are accompanied by an abnormal or absent capillary
system, resulting in a more direct connection between afferent and efferent
vessels. They are unilateral and involve either single or multiple
sites with a predilection for the papillomacular area and the superotemporal
quadrant.31 Both sexes are equally affected. Archer and colleagues divided these communications
into three types based on size of the affected vessels and
condition of the intervening capillary bed.32 Type I is a typical retinal macrovessel associated with an intervening
capillary bed containing abnormally dilated vessels. Archer's type
II retinal arteriovenous communication consists of a dilated and tortuous
artery and vein directly connected, without an intervening capillary
bed. Type III arteriovenous communication is an exaggerated version
of type II, with the artery and vein so aberrant and intertwined that
no distinction between afferent and efferent vessels can be made on
ophthalmoscopic examination (Fig. 6A). Type II and type III malformations also are referred to as racemose, cirsoid
or arteriovenous aneurysms, although they are not true aneurysms.14,33 When arteriovenous communications are large, visual acuity can be severely affected, and the optic nerve tissue can be completely replaced by the anomalous vessels. Vascular sheathing and retinal pigmentary degeneration may occur. Patients with more severe retinal involvement are more likely to have cerebral or periorbital arteriovenous abnormalities, which comprises the Wyburn-Mason syndrome.31 The clinical appearance of these lesions may change over time.34,35 Complications associated with this vascular abnormality include intraretinal hemorrhage, vitreous hemorrhage, aneurysm formation, neovascular glaucoma, macular hole, retinal artery occlusion, and branch or central retinal venous occlusion (see Fig. 6B).36–40 It is hypothesized that retinal arteriovenous communications are associated with localized decreased retinal arterial pressure, increased retinal venous pressure, increased turbulence of blood flow, and decreased perfusion of adjacent retinal tissues to account for these complications.36 IVFA may show rapid dye transit through the arteriovenous communication. There may be adjacent microvascular abnormalities or areas of capillary nonperfusion. Extravascular leakage from these lesions is uncommon. Congenital retinal arteriovenous communications should be distinguished from those acquired secondary to carotid occlusive disease associated with retinal ischemia.41 No successful treatment of these lesions has been reported. Laser photocoagulation may be warranted in some cases with exudative macular involvement or neo-vascular glaucoma.14,37 A racemose or cirsoid retinal arteriovenous communication may represent the ocular manifestation of Wyburn-Mason syndrome, which is one of the phakomatoses.33 This syndrome consists of unilateral retinal arteriovenous communication in conjunction with an ipsilateral arteriovenous malformation of the midbrain.42 The presence of a concomitant systemic arteriovenous communication correlates directly with the grade of retinal arteriovenous communication. Most grade I and II arteriovenous communications appear to represent isolated retinal vascular anomalies.31 Unlike the other phakomatoses, the hallmark ocular lesion of Wyburn-Mason syndrome is not a true hamartoma but is better classified as a hamartia.33 Additional systemic findings in this syndrome include arteriovenous malformations of the bones of the skull, particularly the maxilla and mandible, and, occasionally, facial angiomas.43 Proptosis secondary to an orbital arteriovenous malformation rarely occurs. Wyburn-Mason estimated that 81% of patients with a racemose aneurysm of the retina had an associated intracranial arteriovenous malformation, although other authors believe the actual percentage to be much less.42,44 No hereditary pattern has been identified. |
IDIOPATHIC JUXTAFOVEOLAR RETINAL TELANGIECTASIS | |
Idiopathic juxtafoveolar retinal telangiectasis is characterized by abnormal
retinal capillaries and variable intraretinal exudation after exclusion
of an ocular or systemic cause.45,46 Onset is in adulthood, and patients present with blurred central vision. The
hallmark lesions are small, perifoveal, and parafoveal telangiectatic
capillaries that demonstrate tortuosity, dilation, and irregular
caliber and may be associated with lipid exudation in some cases (Fig. 7). Microaneurysms can be present.47 The abnormal vessels are either localized to an area that usually is temporal
to the fovea and measures between 1 and 5 mm in diameter or scattered
diffusely throughout the macula.45,47 Macular edema or lipid exudation can decrease vision.48 An updated classification by Gass and Blodi in 1993 divides patients based
on biomicroscopic and IVFA features into three groups (1, 2, and 3) and
subgroups (A and B).49 Overall, the telangiectases appear to be related to retinal capillary
leakage in group 1, capillary diffusion abnormalities in group 2, and
capillary occlusion in group 3.
Group 1A is composed of unilateral congenital parafoveal telangiectasis, typically occurring in young to middle-aged male patients. A small area of easily visible retinal vascular abnormalities is present in the temporal macula. There is mild visual loss from macular edema. Laser photocoagulation to areas of leakage may improve vision, Group 1B consists of middle-aged men with a small area of unilateral idiopathic retinal telangiectasis at the edge of the foveal avascular zone, Laser photocoagulation usually is not performed because of the close proximity to the fovea. Group 1 unilateral juxtafoveal telangiectases represent a localized form of congenital retinal telangiectasis (Coats' syndrome). In contrast, group 2 consists of bilateral acquired idiopathic parafoveal telangiectases that become clinically apparent later in the fifth and sixth decade.49 The zones of telangiectasis tend to be symmetric and measure up to 1 disc diameter, with a preference for the temporal parafoveal region. Retinal edema and hard exudates are minimal. So called “right angle” veins are seen draining the telangiectatic areas. Underlying retinal pigment epithelial alterations and superficial retinal refractile deposits can develop. Some patients develop a small, yellow, pseudovitelliform lesion within their fovea. Visual loss usually is mild but can be severe. Pericentral scotomas are common. Later in the course, choroidal neovascularization (CNV), which often is subfoveal, foveolar atrophy, and intraretinal pigment plaques may develop.46 Histopathologic study of bilateral juxtafoveal telangiectasis reveals endothelial cell and pericyte degeneration, as well as retinal capillary narrowing associated with endothelial cell basement membrane proliferation.50 Photocoagulation probably is not beneficial because visual loss appears to result from retinal atrophy rather than exudation; however, it may play a role in treating secondary CNV. Surgical removal of subfoveal CNV has had poor results because of its adherence with the overlying neurosensory retina.51 Group 3 is an uncommon variant with bilateral prominent idiopathic parafoveal telangiectasis and minimal exudation. Visual loss occurs from progressive parafoveal capillary occlusion. There is no leakage from the capillary bed. These patients may have related systemic disease. Retinal vascular telangiectasia also can occur in association with some systemic and ocular conditions. Sickle cell disease and bilateral carotid artery obstruction can mimic the idiopathic version of this condition.52,53 Dilated perifoveal capillaries also have been seen with Stargardt's disease and facioscapulohumeral muscular dystrophy.54,55 Retinal telangiectasia may occur with retinal vein occlusion or radiation retinopathy or represent an atypical presentation of background diabetic retinopathy.56 In one series, 62% of patients with bilateral juxtafoveolar retinal telangiectasis had abnormal glucose metabolism.57 For this reason, all affected patients should undergo a glucose tolerance test and a fasting blood glucose to rule out latent diabetes mellitus. |
CONGENITAL RETINAL TELANGIECTASIS (COATS' DISEASE) |
In 1908, Coats published his findings on patients with retinal diseases
associated with massive subretinal exudation.58 He divided the patients into three groups; (1) those with retinal
vascular disease, (2) those without retinal vascular disease, (3) and
those with a large arteriovenous communication. It
is accepted that Coats' third group were patients with retinal
capillary hemangiomas (von Hippel angiomas).59 Coats' first group consisted of patients with the severe form of
a disease that Reese has since renamed congenital retinal telangiectasis.60 The term Coats' disease should be reserved for patients with congenital retinal telangiectasis
associated with marked hard exudation. Congenital retinal telangiectasis (Coats' disease) is an idiopathic retinal vascular disorder that usually affects young male patients unilaterally in their first or second decade of life. Congenital retinal telangiectasis, however, can affect patients of either gender and become manifest at any age. Up to one third of patients are older than 30 years of age at the time of presentation.14 There is no defined familial inheritance. Patients may present with decreased vision, as well as strabismus or leukocoria in children. The hallmark feature of congenital retinal telangiectasis is localized fusiform aneurysmal dilations of the retinal vessels reminiscent of tiny light bulbs60 (Fig. 8A). These aneurysms and telangiectatic retinal vessels often are adjacent to areas of retinal capillary nonperfusion with dilated intercapillary spaces. The vascular anomalies can occur anywhere in the fundus and may involve the capillaries, arteries, and veins. Other findings may include vascular loops and beading, retinal neovascularization, hemorrhagic retinal macrocysts, and segmentally dilated capillaries.61 Leakage from the incompetent vasculature may lead to retinal edema, lipid deposition, or, in severe cases, an exudative retinal detachment. The extent of retinal involvement is variable. Infants and children often are more severely affected with extensive vascular involvement and massive subretinal lipid exudate. Vascular leakage may produce a cloudy yellow or green subretinal exudate, which gravitates toward the posterior pole. When the serous component of the exudate resorbs, the yellow exudate remains in the macula and may eventually develop into a fibrovascular macular scar. In contrast, a more localized area of telangiectasis may decompensate in adulthood and present as group 1 idiopathic juxtafoveal retinal telangiectasis. IVFA shows aneursymal dilation and leakage from telangiectatic retinal vessels adjacent to areas of retinal capillary dilation and nonperfusion (see Fig. 8B). The clinical course is variable but often progressive. Secondary complications include cataract, vitreous hemorrhage, neovascular or angle-closure glaucoma, CNV, and phthisis bulbi in severe cases. Histopathologic study reveals a characteristic proteinaceous exudate in the subretinal space containing cholesterol clefts and foamy histiocytes. Intraocular calcification rarely has been demonstrated in Coats' disease, which is an important consideration when differentiating this entity from retino-blastoma.62 The syndrome of Leber's miliary aneurysms is a form of congenital retinal telangiectasis that is intermediate in severity. Unilateral, congenital retinal telangiectasis, Leber's miliary aneurysms, and idiopathic juxtafoveal retinal telangiectasis represent the clinical spectrum of a single primary retinal vascular disorder.63 Treatment of congenital retinal telangiectasis is directed to close the leaking telangiectatic vessels to permit resorption of exudate. The treatment modality depends on the location and extent of the lesions.64 Laser photocoagulation is the treatment of choice for small telangiectatic lesions. Cryotherapy may be required for extensive peripheral lesions or for lesions associated with exudative retinal detachments. Multiple treatment sessions may be required. Treatment is directed at the leaking telangiectasis and adjacent zones of capillary nonperfusion. External drainage of subretinal fluid with or without scleral buckling can be used if there is a severe exudative retinal detachment.65 Vitrectomy occasionally is indicated for severe or tractional retinal detachments.66 New telangiectasis may appear in areas of retina that were previously uninvolved; therefore, close follow-up is imperative. Despite successful closure of telangiectasis, visual results may be poor, especially when there is macular exudate at presentation.64 Coats' syndrome or a “Coats-like response” (retinal detachment with massive subretinal exudation) has been associated with other ocular and systemic diseases, including retinopathy of prematurity, branch retinal vein obstruction, retinitis pigmentosa, pars planitis, and muscular dystrophy and hemifacial atrophy.49,67–71 |
CAPILLARY HEMANGIOMA OF THE RETINA |
The capillary hemangioma of the retina (also known as angiomatosis
retinae or von Hippel's disease) was described as a clinical
entity by Eugen von Hippel in 1904.72 The retinal lesions are hamartomas, therefore cytologically benign, and
can be inherited in an autosomal dominant fashion with variable penetrance.73 A sporadic, nonheritable form of the disease probably also exists. There
is no gender preference. These lesions may be more common in whites.33 The association between these retinal vascular tumors and hemangiomatous cysts of the cerebellum was first recognized in 1926 by Lindau, and this association is referred to as von Hippel-Lindau disease.74 von Hippel-Lindau disease is defined as the combination of one or more capillary hemangiomas of the retina in association with a cerebellar hemangioblastoma. This is an autosomal dominant phakomatosis with variable penetrance.43 Many cases occur as a spontaneous mutation, and thus the family history is positive in only approximately 20% of affected persons.43 Lindau estimated that 25% of all patients with retinal lesions have or develop an intracranial mass.74 Other systemic findings associated with von Hippel-Lindau syndrome include pheochromocytoma, renal cell carcinoma (which is the most common cause of death in these patients), and ovarian, pancreatic, and epididymal cysts.43,75,76 Retinal capillary hemangioma is the first manifestation in approximately 50% of these patients.77 When von Hippel-Lindau disease is suspected, systemic workup should include either a MRI or CT scan of the brain with attention to the posterior fossa. An abdominal CT scan and laboratory analysis for the presence of a pheochromocytoma also should be performed.75 When the family history is positive, affected patients require lifelong medical evaluations by an internist, since the protean systemic manifestations can develop years after the retinal tumors are noted.77 The gene for von Hippel-Lindau disease has been localized at 3p25-26, and genetic testing is available for affected patients.78 Retinal capillary hemangiomas also have been reported in neurofibromatosis and Marshall-Stickler syndrome.79,80 Clinically, retinal capillary hemangiomas are smooth, oval, pink or red intraretinal masses (Fig. 9A). Gliosis and retinal pigmentary changes can occur on the lesion surface to alter this appearance.75 Retinal hemorrhage and exudate often surround the tumors. When fully developed, retinal capillary hemangiomas are fed by markedly dilated, often beaded, and tortuous arteries and are drained by similarly appearing veins (see Fig. 9B). When the lesions are small, however, the feeding and draining vessels may not appear abnormal.73 The tumors are typically between 1 and 5 mm, although larger lesions measuring 10 mm have been reported.75 The lesions can occur anywhere in the fundus but are most frequently seen in the temporal equatorial region and on the optic nerve73,75 (Fig. 10A). They are multiple in approximately one third of affected eyes and bilateral in approximately one half of affected persons.73,75,81 Growth of preexisting lesions, as well as development of new retinal capillary hemangiomas in previously uninvolved retina, has been documented. Unusual retinal vascular hamartomas other than retinal angiomas have been detected in patients with von Hippel-Lindau disease and their relatives.82 IVFA demonstrates rapid dye transit through the tumor with profuse leakage of fluorescein during the recirculation phase (see Fig. 10B). Pathologic study of the retinal capillary hemangioma lesions demonstrates thin-walled capillaries surrounded by stromal cells.83 The blood-filled spaces tend to be small.81 The usual age of presentation for a patient with a retinal capillary hemangioma is the second or third decade of life. On occasion, asymptomatic lesions are noted on routine examination. Loss of vision usually occurs when the capillaries associated with the tumor become incompetent and exudate extends into the macula. Even small, peripheral retinal capillary hemangiomas can produce remote exudation into the fovea.75 If these hemangiomas are not treated, total exudative retinal detachment can ensue with secondary iris neovascularization and neo-vascular glaucoma. Epiretinal membranes, vitreous hemorrhage, retinal neovascularization, and both fractional and rhegmatogenous retinal detachments also can occur.84,85 The clinical appearance of retinal capillary hemangiomas located at the optic nerve varies considerably from that of capillary hemangiomas of the retinal periphery. The optic nerve lesions have been described in three varieties.86 The most easily recognized type is the endophytic, which grows anteriorly into the vitreous cavity. It is similar in color and appearance to the peripheral retinal lesions while lacking abnormally dilated feeding and draining vessels (see Fig. 10A). The sessile and exophytic types grow toward the subretinal space and also lack large feeding and draining retinal vessels. The latter two varieties can be difficult to differentiate from peripapillary CNV, choroiditis, choroidal hemangiomas, or optic nerve edema. Stereoscopic IVFA may help to differentiate these entities.86 Clinically, sessile hemangiomas appear as flat, ill-defined, yellow-orange lesions visible underneath grayish, thickened overlying retina. The endophytic type is similar in appearance but has a nodular growth pattern. Visual loss occurs secondary to serous or exudative fluid that extends into the macula, often with hard exudate, Rarely does the serous retinal detachment become as severe as with peripheral retinal capillary hemangiomas. Optic disc and retinal capillary hemangiomas can occur in the same eye together, or a patient can have a disc hemangioma in one eye with a retinal hemangioma in the other. Bilateral optic disc capillary hemangiomas have been described.87 Retinal capillary hemangioma can simulate congenital retinal telangiectasis with exudative detachment (Coats' disease). The lack of either “light bulb” telangiectasis or peripheral retinal capillary nonperfusion on IVFA, coupled with the presence of feeding and draining vessels leading to a retinal mass, usually reveals the proper diagnosis. Other entities in the differential diagnosis are grade III arteriovenous communications and cavernous hemangiomas of the retina. Based on the natural history of progressive visual loss and their potential for growth, most authorities recommend some type of obliterative therapy, even when the visual acuity is unaffected. The treatment modality depends on the size, location, and number of lesions. Retinal capillary hemangiomas can be treated with laser photocoagulation or cryotherapy, diathermy, or radiotherapy.73,88–92 Techniques for laser photocoagulation include direct treatment of the lesion, laser to the feeding arteriole to reduce tumor blood flow before direct treatment, and scatter treatment around the lesion to prevent posttreatment extension of exudate. Radiotherapy is a newer treatment for this entity. Plaque radiotherapy appears useful for lesions with extensive exudative detachments, whereas charged particle beam irradiation may be used for epipapillary lesions.92 Peeling of epiretinal macular membranes has been reported after obliteration of peripheral lesions.84 On occasion, obliterative treatment may lead to total exudative retinal detachment (ablatio fugax) or vitreous hemorrhage. Vitrectomy may be indicated for severe exudative or fractional retinal detachment.73,85,93 Eye wall resection has been attempted to treat exceptionally large tumors.94 Despite treatment, the prognosis for visual acuity with larger lesions remains guarded.75,95 In contrast, retinal capillary hemangiomas of the optic disc usually are not treated unless they become symptomatic. Obliterative treatment strong enough to destroy the tumor at the optic nerve can result in total loss of vision. |
VASOPROLIFERATIVE TUMORS OF THE FUNDUS |
Shields and associates describe 12 patients with fundus lesions that resembled
retinal capillary hemangiomas on clinical examination but were
believed to develop on an acquired basis.96 These lesions were characterized as a vascularized mass of the sensory
retina with a yellow-red appearance but lacked the enlarged, tortuous
feeding and draining vessels typically seen with von Hippel-Lindau retinal
capillary hemangiomas. Also, there was no association found with
von Hippel-Lindau disease in these individuals, although 50% had
known systemic hypertension. The term presumed acquired retinal hemangiomas initially was coined to describe this entity. Campochiaro and Conway report
five additional patients with similar lesions.97 Other authors have used terms such as hemangioma-like, angioma, angiomatous
mass, and acquired peripheral retinal telangiectasis to describe
this entity.98–100 In 1995, Shields and associates characterized 103 patients with these acquired retinal hemangiomas and recommended using the term vasoproliferative retinal tumors to describe these lesions.101,102 The lesions can be unilateral or bilateral and are characterized as either idiopathic (primary) or secondary to preexisting ocular disease. Associated preexisting ocular disorders include intermediate uveitis, retinitis pigmentosa, toxoplasmosis, toxocariasis, his-toplasmosis, retinochoroidal coloboma, traumatic chorioretinopathy, familial exudative vitreoretinopathy, Coats' disease, status postretinal detachment repair, and cryotherapy.100,102 Lesions usually are solitary but can be multiple or diffusely involve the eye and have a propensity to occur in the inferior peripheral retina. Associated ocular findings that may impair vision include intraretinal exudation, exudative retinal detachment, vitreous cells, vitreous hemorrhage, retinal pigment epithelial hyperplasia, premacular fibrosis, and macular edema. The macular changes may be remote from the vasoproliferative tumor. IVFA reveals rapid filling of the vasoproliferative tumor through an undilated or minimally dilated retinal arteriole in the arterial phase and staining of the lesion in the late phases.102 Ultrasonography reveals medium to high internal reflectivity and acoustic solidity without choroidal excavation.102 The pathogenesis of vasoproliferative retinal tumors is not clear. It has been hypothesized that these lesions represent exuberant vascularization of the retina or retinal pigment epithelium or reactive gliosis.101,102 Histopathologic study in one case demonstrated retinal gliosis, dilated ectatic retinal vessels, and a preretinal neovascular membrane.103 Management of these lesions has included observation, cryotherapy, laser photocoagulation, and plaque radiotherapy, depending on the size and location of the lesion and the associated complications.97,102,104 |
CAVERNOUS HEMANGIOMA OF THE RETINA |
Cavernous hemangioma of the retina is a rare benign vascular hamartoma
that can arise anywhere in the fundus or from the optic nerve. Reese initially
described this clinical entity, although Gass is credited as
definitively identifying retinal cavernous hemangiomas as distinct from
von Hippel lesions or congenital retinal telangiectasis.17,105 The cavernous hemangioma of the retina usually is sporadic, although occasional
familial cases have been reported, and it may be more common
in women.14 These lesions are congenital but usually are not detected until the second
decade. Ophthalmoscopically, they have a distinctive appearance. Cavernous hemangiomas of the retina consist of multiple, elevated saccular lesions arising from the inner retina, giving the appearance of a cluster of grapes (Fig. 11A and B). Each saccule measures from 100 μm to as large as 1500 μm, with the entire lesion typically measuring between 2 and 6 mm.75 The saccules typically appear dark red and are adjacent to a retinal vein. Individual aneurysms may occur separate from the main lesion. Lipid exudation rarely occurs, although associated gliosis may impart a whitish, fibrous, plaque-like-appearance to its surface.105 Hemorrhage on the surface of the lesion has been noted, and vitreous hemorrhage also can occur.105 Growth of these lesions is rare.73,106 Unlike the retinal capillary hemangioma of von Hippel, the surrounding retinal vessels are of normal caliber.107,108 On IVFA, the lesions usually fill slowly, and late leakage of dye is uncommon. A plasma erythrocyte level often is seen within some of the sacculi on IVFA (see Fig. 11C). Visual loss is uncommon, but when it is present, it usually occurs secondary to vitreous hemorrhage. Epiretinal membrane formation, foveal dragging, and am-blyopia also have been reported. Treatment of these lesions is rarely indicated. On occasion, cryotherapy, laser photocoagulation, or vitrectomy may be performed for recurrent visually disabling vitreous hemorrhage.106 Histopathologic study shows large, blood-filled vascular spaces in the inner retina (Fig. 12). Cavernous hemangioma of the retina has been implicated as a part of an oculoneural cutaneous syndrome.109,110 Associated lesions include hemangiomas of the skin, especially on the back of the neck, as well as seizures, presumably from hemangiomas of the brain. The brain hemangiomas usually occur in the midbrain or cerebral cortex and can be difficult to detect with arteriography or CT scanning.111 Individuals with this syndrome are more likely to have multifocal or bilateral retinal cavernous hemangiomas,109 |
CHOROIDAL HEMANGIOMA |
Choroidal hemangiomas are congenital hamartomatous vascular tumors that
occur in two clinically and histopathologically distinct varieties: circumscribed
and diffuse. Circumscribed choroidal hemangiomas are discrete, smooth-surfaced tumors and are characteristically round or oblong33,112 (Fig. 13A). They usually measure between 2 and 6 mm in diameter, although up to 17 mm diameter has been reported.109 Thickness varies from 1 to 6 mm. They usually are found in the macular area or peripapillary region, and the posterior tumor margin typically is located within two disc diameters from the fovea or optic nerve.113,114 Their coloration is a characteristic reddish orange. This distinct color allows them to be differentiated from other amelanotic choroidal tumors. When flat, choroidal hemangiomas can be difficult to differentiate from the background choroidal pattern. Although they are vascular, choroidal hemangiomas rarely show large, distinct, inherent tumor vessels on ophthalmoscopic examination. Retinal pigment epithelial alterations frequently occur over the surface of these lesions. Fibrous metaplasia of the retinal pigment epithelium commonly occurs with time and results in a whitish plaque-like surface. Cystoid degeneration of the overlying retina or even bullous retinoschisis also, can develop.112 Retinal neovascularization and CNV have been described.115,116 Decreased vision secondary to associated serous subretinal fluid is the usual reason affected patients seek medical attention. This decreased vision most commonly occurs in the third to fifth decade of life. Total exudative retinal detachment with shifting fluid can develop. Circumscribed choroidal hemangiomas occasionally enlarge slightly over prolonged observation.117 IVFA shows early filling of the hemangioma concomitant with the choroidal circulation, although this pattern is variable and nondiagnostic33 (see Fig. 13B). ICG angiography is more useful than IVFA to define circumscribed choroidal hemangiomas. ICG dye fills the intralesional vessels early. There is intense ICG hyperfluorescence in the mid-angiogram (see Fig. 13C), followed by late clearing of the dye with a “washout” phenomenon. 118,119 Ultrasonography reveals a placoid choroidal mass with acoustic solidity and high internal reflectivity secondary to multiple interfaces within the tumor. In the past, many eyes containing circumscribed choroidal hemangiomas were enucleated because the lesions were confused with amelanotic choroidal melanomas. Careful ophthalmoscopic examination, with attention to the lesion's color and the presence of inherent uveal pigmentation or large, distinct choroidal vessels, usually provides the correct diagnosis. Other lesions in the differential diagnosis include choroidal granuloma, metastatic tumor, and choroidal osteoma. Angiography (IVFA, ICG) and ultrasonography are helpful in differentiating these entities. Circumscribed choroidal hemangiomas are not inherited and are not associated with systemic abnormalities. Diffuse choroidal hemangiomas are larger and flatter than the circumscribed variety, with more indistinct borders.33 This lesion resembles diffuse choroidal thickening, but some nodular thickening can occur in the posterior pole. Diffuse choroidal hemangiomas commonly cover over one half of the fundus, extending into the equatorial zone. The lesion imparts a bright red reflex to the fundus, resulting in the so-called “tomato catsup” fundus.33 Comparison of this red reflex with a normal opposite eye can be helpful in confirming the diagnosis. On ophthalmoscopic examination, the normal underlying choroidal pattern is obscured. The overlying retinal vessels also may be affected. Dilation and tortuosity of the retinal vessels, as well as peripheral arteriovenous communications, have been noted.112 Exudative retinal detachment can occur. Ultrasound of the diffuse variety demonstrates generalized choroidal thickening and optic nerve cupping. Both MRI and CT scan can show diffuse choroidal hemangioma.120 Diffuse choroidal hemangiomas are associated with Sturge-Weber syndrome (encephalotrigeminal angiomatosis), a noninherited phakomatosis, or a variant such as Klippel-Trenaunay-Weber or Milles' syndrome.43,112,113,121 The Sturge-Weber triad consists of a facial nevus flammeus (a large vascular telangiectasia, not a true hemangioma), ipsilateral buphthalmos, and contralateral seizures caused by ipsilateral leptomeningeal hemangiomatosis. The diffuse choroidal hemangioma is not a requisite part of the syndrome. It is present in approximately 50% of affected persons and can be bilateral.122 The associated glaucoma can be infantile, juvenile, or neo-vascular. When a person has an isolated nevus flammeus without the full Sturge-Weber syndrome, the probability of having an accompanying diffuse choroidal hemangioma is about 2%.33 Like the circumscribed variety, diffuse choroidal hemangioma can lead to exudative retinal detachment, secondary retinal and iris neovascularization, and neovascular glaucoma. Pathologic study of choroidal hemangiomas shows a distinct tumor with dilated, blood-filled spaces lined by endothelium.113 Often, the overlying retinal pigment epithelium reveals hyperplasia, metaplasia, or even ossification. The overlying retina can demonstrate outer plexiform cystic changes. Most circumscribed choroidal hemangiomas are either of the pure cavernous type or the mixed cavernous and capillary type. The diffuse tumors usually are composed of both capillary and cavernous components.33 When symptomatic, circumscribed choroidal hemangiomas can be treated with obliterative therapy. Both light scatter argon laser photocoagulation to the tumor's surface and intense obliteration with either argon or krypton laser or xenon photocoagulation have been advocated.111 Multiple treatments may be required because of reaccumulation of sub-retinal fluid. Diode laser hyperthermia without photocoagulation is being investigated as an alternative treatment.123 Cryotherapy and penetrating diathermy are of limited use because of the posterior location of the tumors. Radiation therapy has been used with success in eyes with thick choroidal hemangiomas and bullous nonrhegmatogenous retinal detachments, and eyes that have not responded to other modalities.124,125 External beam irradiation and plaque and proton beam radiotherapy have been used. On occasion, external drainage of subretinal fluid with or without scleral buckling in conjunction with laser photocoagulation has been used to treat diffuse choroidal hemangiomas associated with large exudative retinal detachments.33 Alternatively, vitrectomy, endolaser, and internal drainage of subretinal fluid can be performed. The visual prognosis remains guarded because of significant secondary retinal changes that can occur over the tumor's surface and the lesion's propensity for recurrent leakage. |
IDIOPATHIC POLYPOIDAL CHOROIDAL VASCULOPATHY |
Idiopathic polypoidal choroidal vasculopathy (IPCV), also known
as posterior uveal bleeding syndrome or multiple recurrent serosanguineous
retinal pigment epithelial detachment syndrome, is characterized
by choroidal vascular anomalies.126–128 It is more common in middle-aged women and is associated with African-American
race and systemic hypertension.129 The lesions in IPCV are unilateral or bilateral orange-red subretinal
polypoidal saccular dilations arising from an inner choroidal vascular
network130 (Fig. 14A). The polypoidal lesions typically originate from the peripapillary
choroidal circulation but also have been described in the macular region
and in the peripheral fundus.131 Visual loss may result from subretinal hemorrhage, vitreous hemorrhage, or
subretinal exudate from the polypoidal lesions. IVFA angiography
reveals hyperfluorescence and pooling of fluorescein in the polypoidal
choroidal lesions. ICG angiography characteristically reveals a dilated
network of inner choroidal vessels, which terminate in multiple saccular
dilations that correspond clinically to the orange subretinal lesions130,132 (see Fig. 14B).
Differentiation of IPCV from CNV secondary to age-related macular degeneration is important, since the treatment and prognosis of these entities differs. IPCV is differentiated from age-related macular degeneration by the absence of drusen and subretinal fibrosis, as well as its characteristic clinical and ICG features. The optimal management of IPCV is not clear. Lesions with hemorrhagic complications can present acutely with visual loss but occasionally resolve spontaneously with visual recovery. Laser photocoagulation of the polypoidal lesions may be considered if subretinal fluid, exudate, or hemorrhage threatens or involves the fovea.130 |
IDIOPATHIC RETINAL VASCULITIS, ANEURYSMS AND NEURORETINITIS |
Idiopathic retinal vasculitis, aneurysms, and neuroretinitis (IRVAN) is
an uncommon syndrome characterized by retinal vasculitis, multiple
macro-aneurysms, neuroretinitis, and peripheral retinal capillary
nonperfusion.133 This initially was described in detail by Schatz and Kincaid in two patients
with bilateral retinal arteritis, multiple macro-aneurysms, neuroretinitis, and
uveitis.134 Thirteen additional patients have been reported with this disorder,133,135–137 It is not clear whether this syndrome is a primary vascular or inflammatory
disorder, but it is included in this chapter based on its unusual
retinovascular features. This syndrome typically affects young healthy individuals with a female preponderance. Despite the significant retinal findings, patients often are asymptomatic at presentation. In the largest series of 10 patients, all three features described by the acronym IRVAN were required for diagnosis.133 This includes the presence of numerous aneurysmal dilations of the optic nerve head and retinal arterioles at or near their major branching sites. The aneurysms measure between 75 and 300 μm in diameter and may have a triangular, Y-shaped or coiled configuration. Aneurysmal changes at the optic nerve head may be associated with ectatic changes and apparent elongation of the adjacent arteries (Fig. 15A). The vascular abnormalities in IRVAN have a propensity to leak, leading to exudative retinopathy, but do not have a predisposition to hemorrhage. Subretinal, intraretinal, or vitreous hemorrhage secondary to aneurysms has not been associated with IRVAN. This is contrasted with senile acquired macroaneurysms, which occur in older individuals with systemic hypertension, are round, and may be associated with either hemorrhage or serous exudation. IVFA is useful to delineate aneurysmal changes in IRVAN. Vasculitis is demonstrated by staining of the arterial and venous walls on IVFA, and the arterioles appear to be more severely affected (see Fig. 15B). Neuroretinitis is manifested clinically as optic nerve head swelling and as late diffuse staining of the optic nerve head on IVFA. Extensive peripheral retinal capillary nonperfusion with sequelae of retinal ischemia, such as neovascularization of the retina or anterior segment, may occur. Vitreous hemorrhage may occur secondary to retinal neovascularization. Vitritis has been described in IRVAN and may be accompanied by anterior uveitis. IRVAN is differentiated from Bales' disease, which has a predilection for young male patients, an association with tuberculin hypersensitivity, more marked uveitis, retinal venous inflammation, and a lack of multiple macroaneurysms.133 Although some cases of IRVAN maintain good visual acuity, severe visual loss may result from exudative maculopathy or sequelae of retinal ischemia. Extensive medical investigations have not revealed any systemic associations. Systemic corticosteroids do not appear to have a beneficial effect on uveitis or retinal ischemia. There is limited experience regarding laser photocoagulation to aneurysms to treat eyes with exudative retinopathy threatening the fovea. Branch artery occlusion was described in one case after laser photocoagulation to a single aneurysm.133 Chang and colleagues recommend observing eyes without retinal neovascularization and performing panretinal laser photocoagulation for eyes that have developed retinal neovascularization or have signs of rapidly progressive anterior segment ischemia.133 Vitrectomy has been performed for eyes with persistent vitreous hemorrhage. |
VARIX OF THE VORTEX VEIN |
A varix of the vortex vein represents a large dilation of the vortex vein
ampulla that may be noted during indirect ophthalmoscopic examination. It
typically becomes more prominent when the eye is directed in eccentric
gaze, and it often is located at the equator in the nasal retina.138 This entity is asymptomatic and may be overlooked during examination. On
occasion, a varix of the vortex vein may be large enough to simulate
a solid choroidal lesion such as a small choroidal melanoma.138–140 However, the clinical features and dynamic nature of a vortex vein varix
are characteristic for this entity. The varix appears as a dark red, smooth, dome-shaped elevation located deep to the retina. It can measure between 3 and 6 mm in diameter and up to 2.5 mm in thickness.138 It can be unilateral or bilateral, and more than one varix may be noted within one eye.138,141 It is typically reported in middle-aged to elderly patients, although it has been noted in patients as young as 23 years,142 There are no known systemic associations. The varix can compress the adjacent choroid, which increases visibility of choroidal pigment at the edge of the ampulla. This feature may lead to diagnostic confusion with choroidal melanoma. The continuity of the lesion with the choroidal vasculature and the fluctuating nature of the varix are helpful to confirm its diagnosis. The varix becomes more prominent with positioning of the affected eye in the direction of the varix (Fig. 16A). Also, the varix may become engorged by the Valsalva maneuver or by lowering the individuals head below the level of the heart.141 Positioning the eye in primary position, elevating the head, or applying pressure on the globe digitally or with a contact lens can make the varix less prominent or cause it to disappear140 (see Fig. 16B). The pathogenesis of a varix of the vortex vein has been attributed to gaze-evoked kinking of the extrascleral portion of the vortex vein, gaze-evoked narrowing of the scleral emissary canal, and increased ocular venous pressure.139,141,143 Diagnostic tests include B-scan ultrasound, IVFA, ICG angiography, and color Doppler imaging. B-scan ultrasound reveals acoustic solidity and gaze-evoked enlargement of the lesion. Increased intraocular pressure induced by the ultrasound probe may cause the lesion to disappear.139 Low to medium internal reflectivity is noted on Ascan. IVFA shows mild patchy choroidal fluorescence of the vortex vein ampulla in the venous phase with late pooling of dye in the outer choroid. ICG angiography reveals early hyperfluorescence with late pooling of dye in the varix, and gaze-evoked fluctuation of ICG hyperfluorescence may be noted143 (see Fig. 16C and D). Color Doppler imaging shows a vascular lesion of venous origin that fills when the eye is directed to the quadrant of the lesion.144 |
